Equipment for selecting vanadium titanium sand

Equipment for selecting vanadium titanium sand

Vanadium titanium sand is an important metal mineral resource widely used in fields such as steel, aviation, aerospace, and military industry. The equipment for selecting vanadium titanium sand is one of the important equipment for processing vanadium titanium sand. This article will introduce the relevant knowledge and operating steps of vanadium titanium sand selection equipment.

1、 Classification of vanadium titanium sand selection equipment

The equipment for selecting vanadium titanium sand is mainly divided into several types, including heavy medium beneficiation machines, magnetic separators, flotation machines, vibrating screens, etc.

1. Heavy medium concentrator

A heavy medium beneficiation machine is a physical beneficiation method that utilizes heavy media of different densities to separate ores. This equipment is suitable for the beneficiation of coarse particles and has the characteristics of large processing capacity and good beneficiation effect.

2. Magnetic separator

A magnetic separator is a device that uses magnetic substances to separate minerals. The magnetic separator is suitable for separating magnetic minerals with small particle size, such as Magnetite, Hematite, etc.

3. Flotation machine

A flotation machine is a device that utilizes the different affinity between minerals and bubbles for separation. The flotation machine is suitable for separating non-metallic minerals and certain metallic minerals, such as copper, lead, zinc, etc.

4. Vibration screen

A vibrating screen is a device that uses vibration force to screen ore. The vibrating screen is suitable for screening coarse, medium, and fine particles, with high screening efficiency and large processing capacity.

2、 Operation steps of vanadium titanium sand selection equipment

1. Preparation work

Before using the vanadium titanium sand selection equipment, it is necessary to install and debug the equipment. Firstly, it is necessary to check whether all parts of the equipment are securely installed, and then connect the electrical wiring and gas interface. Next, the equipment needs to be debugged to check whether the operation of the equipment is normal.

2. Feed

Place the vanadium titanium sand ore into the feeding port of the concentrator, open the feeding valve, and control the feeding amount and speed.

3. Selection

Select the corresponding sorting method based on the different principles of the concentrator. The heavy medium concentrator needs to adjust the density and flow rate of the heavy medium, the magnetic separator needs to adjust the magnetic field strength and magnetic material performance, the flotation machine needs to adjust the size and concentration of bubbles, and the vibrating screen needs to adjust the aperture and vibration frequency of the screen.

4. Closing work

After the sorting is completed, close the feed valve and stop the operation of the concentrator. Clean up residues and impurities inside the equipment, and carry out maintenance and upkeep of the equipment.

III. Conclusion

The equipment for selecting vanadium titanium sand is one of the important equipment for processing vanadium titanium sand. Choosing a suitable concentrator is of great significance for improving the grade and recovery rate of vanadium titanium sand. When using vanadium titanium sand sorting equipment, it is necessary to operate according to different sorting methods to ensure the normal operation of the equipment and the beneficiation effect.
